Fanless Embedded System
with LGA1151 Socket 7th/6th Gen Intel® Core™ & Celeron® Processor,
Intel® Q170, 2 HDMI, DisplayPort, 4 GbE LAN, 8 USB, 2 PCI Express Mini
Card Slots
产品特点
-
LGA1151 socket 7th/6th gen Intel® Core™ i7/i5/i3 & Celeron® processors (Kaby Lake/Skylake)
-
1 DisplayPort and 2 HDMI (1 HDMI 2.0) with triple view supported
-
Supports Jumbo Frame (9.5k), WoL, PXE Remote Boot, Teaming
-
9 to 36 VDC wide range power input
-
Flexible I/O window design
-
AMS.AXView intelligent remote monitoring software for IIoT
产品介绍
The eBOX670-891-FL supports the 7th/6th
generation Intel® Core™ i7/i5/i3 and Celeron® processors with flexible
I/O configurations. This outstanding embedded box PC is equipped with
dual DDR4-2133 SO-DIMM slots with system memory up to 32 GB. The
eBOX670-891-FL provides high flexibility with reserved I/O module space
on the rear side. The embedded system integrator can expand the system
quickly and easily by installing suitable I/O modules. The fanless
embedded box computer features wireless communication capabilities with
two internal PCI Express Mini Card slots and one SIM card slot. Four
Gigabit Ethernet ports are for customers who need mass data transmission
or LAN port teaming functions for each virtual machine. For storage
needs, it is equipped with one easy-access CFast™ socket, one mSATA
interface, and dual 2.5” SATA hard drive bays with RAID 0&1 support.
