Fanless Embedded System with Intel® Atom® x5-E3940 1.8 GHz, HDMI, VGA, 2 GbE LAN, 6 USB and 3 COM
产品特点
-
Intel® Atom® x5-E3940 onboard
-
204-pin DDR3L-1866 SO-DIMM for up to 8GB of memory
-
Supports 2 GbE LAN, 3 COM and 6 USB
-
One 2.5” SATA drive bay and mSATA supported
-
Trusted Platform Module (TPM) 1.2
-
2 PCI Express Mini Card slots and 1 SIM slot
-
-40°C to +60°C operating temperature range
-
AMS.AXView intelligent remote monitoring software for IIoT
产品介绍
The eBOX626-311-FL is powered by the
Intel® Atom® processor x5-E3940. The fanless embedded box PC was
designed to operate reliably in industrial environments – with an
IP40-rated enclosure, extended -40°C to +60°C support, and 3 Grms
vibration resistance. To ensure system security, it utilizes the Trusted
Platform Module (TPM) 1.2 function. The embedded box computer
eBOX626-311-FL is well-suited for industrial controllers, intelligent
robotic control, intelligent gateway systems, smart kiosks, visual
inspection and data visualization.
