ATX Motherboard with
LGA1151 Socket 9th/8th Gen Intel® Core™ i7/i5/i3, Xeon® E, Pentium® or
Celeron® Processor, Intel® C246, ECC DDR4, USB 3.1 Gen2, SATA 3.0, Dual
LAN, VGA, DisplayPort++, DVI-D, and HDMI
产品特点
-
LGA1151 socket 9th/8th gen Intel® Core™ i7/i5/i3, Xeon® E, Pentium® or Celeron® processor (Coffee Lake Refresh)
-
Four 288-pin DDR4-2666/2400 ECC DIMM for up to 128GB of memory
-
DisplayPort++, VGA, DVI-D and HDMI with triple-view supported
-
4 SATA-600 with RAID 0/1/5/10
-
2 USB 3.1 Gen2 and 4 USB 3.1 Gen1
-
TPM 2.0 supported (optional)
产品介绍
The IMB521R is powered by the LGA1151
socket 9th and 8th generation Intel® Core™ i7/i5/i3 (code name: Coffee
Lake Refresh), Intel® Pentium® or Intel® Celeron® processor with
the Intel® C246 chipset. The industrial motherboard is designed with
rich functionality and offer high processing powers, multiple expansion
interfaces, security feature, and stunning graphical performance to
deliver true customer value and quick deployment in a broad range of
high-performance applications such as industrial automation, gaming,
AI-related server, self-service kiosks, medical, and digital signage. It
features one PCIe x16 slot, four PCIe x4 slots, one PCIe x1 slot and
one PCI slot for future expansions such as motion control cards, frame
grabber cards or data acquisition cards. It also has two USB 3.1 Gen2
and four USB 3.1 Gen1 ports for faster data transfer. In addition, the
industrial-grade ATX motherboard is integrated with the Intel® HD
Graphics to deliver stunning 4K resolution, as well as fast 3D and video
playback for graphics-intensive applications. It support three
independent displays with DisplayPort++, DVI-D, HDMI, and VGA.
