ATX Motherboard with
LGA1151 Socket 9th/8th Gen Intel® Core™, Xeon® E Processor, Intel® C246,
USB 3.1 Gen2, SATA 3.0, PCI Express Mini Card Slot, VGA, DisplayPort++,
DVI-D, and HDMI
产品特点
-
LGA1151 socket 9th/8th gen Intel® Core™ i7/i5/i3, Xeon® E, Pentium® or Celeron® processor (Coffee Lake Refresh)
-
Four 288-pin DDR4-2666/2400 ECC DIMM for up to 128GB of memory
-
DisplayPort, DVI-D, HDMI and VGA with triple-view supported
-
5 SATA-600 with RAID 0/1/5/10
-
1 PCI Express Mini Card slot
-
2 USB 3.1 Gen2 and four USB 3.1 Gen1
-
TPM 2.0 supported (optional)
产品介绍
The IMB525R is powered
by the Intel® Xeon® E, 9th/8th generation Intel® Core™, Intel® Pentium®
or Intel® Celeron® processors with the Intel® C246 chipset. The
server-grade ATX motherboard offers optimum processor performance,
unparalleled flexibility, rich I/O expandability and superior graphics
performance; additionally, the server-grade platform supports
Error-Correcting Code (ECC) memory which provides improved data
integrity and system reliability through automatic data correction. It
also features five SATA-600 ports with software RAID 0/1/5/10 for
reliable data storage and protection. The IMB525R is specifically suited
for industrial workstations, embedded networks, factory automation,
robotic motion control, machine vision, and testing and measurement.
