ATX Motherboard with
LGA1151 Socket 9th/8th Gen Intel® Core™ Processor, Intel® H310, USB 3.1
Gen1, SATA 3.0, PCI Express Mini Card Slot, VGA, DisplayPort++, DVI-D,
and HDMI
产品特点
-
LGA1151 socket 9th/8th gen Intel® Core™ i7/i5/i3,
-
Pentium® & Celeron® processor (Coffee Lake Refresh)
-
Two 288-pin DDR4-2666/2400 DIMM for up to 64GB of memory
-
DisplayPort++, DVI-D, HDMI and VGA with dual-view supported
-
4 SATA-600
-
1 PCI Express Mini Card slot
-
4 USB 3.1 Gen1 and 5 USB 2.0
-
TPM 2.0 supported (optional)
产品介绍
The IMB524R is powered by the LGA1151
socket 9th/8th generation Intel® Core™, Intel® Pentium® or Intel®
Celeron® processor with the Intel® H310 chipset. It has two 288-pin
DDR4-2666/2400 DIMM sockets with a memory capacity of up to 64GB.
The IMB524R offers rich expandability with a PCIe x16 slot, two PCIe x4
slots, four PCI slots and a PCIe Mini Card slot in support of
add-on-card expansibilities, such as motion control cards, frame grabber
cards or data acquisition cards. In addition to its excellent
computing performance, the IMB524R is designed to deliver substantial
expansion flexibility and stunning graphical performance for diverse
industrial IoT applications, such as industrial automation, self-service
kiosk, medical imaging, digital signage, robotics, and machine control.
