产品特点
-
LGA1151 socket 9th/8th gen Intel® Core™ i7/i5/i3, Pentium® & Celeron® processor (Coffee Lake Refresh)
-
Four 288-pin DDR4-2666/2400 DIMM for up to 128GB of memory
-
DisplayPort, DVI-D, HDMI and VGA with triple-view supported
-
5 SATA-600 with RAID 0/1/5/10
-
1 PCI Express Mini Card slot
-
Two USB 3.1 Gen2 and four USB 3.1 Gen1
-
TPM 2.0 supported (optional)
产品介绍
The IMB523R is powered
by the LGA1151 socket 9th/8th generation Intel® Core™, Intel® Pentium®
or Intel® Celeron® processor with the Intel® Q370 chipset. In addition
to its excellent computing performance, the IMB523R delivers superior
graphics performance with the Intel® HD Graphics. Additionally, the
IMB523R offers rich expandability with a PCIe x16 slot, two PCIe x4
slots, four PCI slots and a PCIe Mini Card slot in support of
add-on-card expansibilities, such as motion control cards, frame grabber
cards or data acquisition cards. To meet the needs of high-density
computing applications, the IMB523R comes with four 288-pin
DDR4-2666/2400 DIMM sockets with up to 128GB of system memory. For a
wide range of user configurations, the IMB523R has two USB 3.1 Gen2,
four USB 3.1 Gen1 and seven 180D type A USB 2.0 ports. To enhance data
recovery capability, the IMB523R features five SATA-600 sockets with
RAID 0/1/5/10 function. The IMB523R also offers triple display
configurations via DVI-D, VGA, HDMI and DisplayPort++ ports.
